Oscilloscopio Rigol digitale compatto DS8204 R 2GHz. 10GSa s. ( 4 CH ) Piper Perri Step Sis Hot Porn Watch and Download Piper Perri Step Sis. La serie DS8000 R identifica oscilloscopi digitali di fascia medio alta di dimensioni compatte progettati sulla base del chip ASIC (dove RIGOL ne possiede i diritti di propriet intellettuale) e sulla piattaforma tecnica UltraVision II anch'essa sviluppata da RIGOL. Il design di questi strumenti compatto , sottile. Sono strumenti integrabili in piu' quantit nei sistemi di collaudo , sono facilmente installabili a rack e sono utilizzabili in remoto per soddisfare i requisiti sempre piu' importanti di una completa automazione industriale. La serie prevede una larghezza di banda analogica fino a 2 GHz, supporta l'attivazione sincrona multi dispositivo che consente l'estensione fino a 512 canali. L'oscilloscopio della serie DS8000 R fornisce un'ottima soluzione per soddisfare i requisiti di velocit medio alta , per integrare piu' strumenti in un unico sistema , per consentire la sincronizzazione di acquisizione dati multicanale. Specifiche tecniche: Model DS8204 R Analog bandwidth (50 , 3dB) 2GHz Calculated Rising Time under 50 225 ps Max. Sample Rate of Analog Channel 10 GSa s (single channel), 5 GSa s (half channel), 2. 5 GSa s (all channels) Peak Detection capture 400 ps glitches Max. Memory Depth 500 Mpts (single channel), 250 Mpts (half channel ), 125 Mpts (all channels) Hardware real time waveform recording and playing 450,000 wfms s (single channel) Max. Waveform Capture Rate 600,000 wfms s No. of Input Output Channels 4 input analog channels 1 input EXT channel Arbitrary waveform generator output (required to purchase the DS8000 R AWG option)Sampling Mode Real time sampling Sampling Mode Real time sampling Caratteristiche principali serie DS8000 R Analog channel bandwidth: 350 MHz, 1 GHz, and 2 GHz Up to 10 GSa s real time sample rate (for DS8104 R DS8204 R), 5 GSa s (for DS8034 R) 4 analog channels, 1 EXT input channel Standard memory depth up to 500 Mpts High waveform capture rate (over 600,000 wfm s) Low jitter, multiple device synchronization (<200 psRMS, typical) High speed data communication interface (10 GE SFP+), ensuring the reliable transmission of massive data Integrates 6 independent instruments into 1, including digital oscilloscope, spectrum analyzer, AWG (option), digital voltmeter, 6 digit counter and totalizer, and protocol analyzer (option) Available to be extended to 512 channels, supporting synchronous acquisition (with the multi channel synchronization module) Real time eye diagram and jitter analysis software (option for DS8104 R DS8204 R, but unavailable for DS8034 R) Built in advanced power analysis software (option) Operating temperature low below 40?, available to be used for signal monitoring in some special conditions Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), 10 GE SFP+, HDMI, TRIG OUT, 10 MHz In, and 10 MHz Out Web Control remote command Compact and thin design, save rack space, 1U rack mount kit (standard) Software development kit available for users to meet their customized development according to their specific scenarios Easy to use on site multi channel synchronization calibration kit, enabling you to view multiple channels synchronously Rigol DS8000 R datasheet Rigol DS8000 R userguide
